High-Accuracy Measurement: Ensures precision in critical engineering applications.
Robust Design: IP65-rated for durability and protection against dust and water.
Versatile Applications: Suitable for electronics, plastics, and machinery testing.
Product descriptions from the supplier
Highlights at a glance
High-Accuracy Measurement: Ensures precision in critical engineering applications.
Robust Design: IP65-rated for durability and protection against dust and water.
Versatile Applications: Suitable for electronics, plastics, and machinery testing.
Reliable Warranty: Comes with a 1-year guarantee for peace of mind.
User-Friendly: Easy-to-use interface with standard controls.
III. Specifications
| Code | 04171... |
001 YF-2010 |
002 YF-3020 |
003 YF-4030 |
004 YF-5040 |
| Model | |||||
| Table | Metal Table Dimension (mm) | 404*228 | 500*330 | 606*466 | 706*606 |
| Glass Table Dimension (mm) | 260*160 | 350*280 | 450*350 | 550*450 | |
| XY Stroke (mm) | 200*100 | 300*200 | 400*300 | 500*400 | |
| Load Capacity | approx. 15 kg | approx. 20 kg | approx. 30 kg | approx. 35 kg | |
| Weight (kg) | 180 | 260 | 315 | 500 | |
| Dimension (L*W*H, mm) | 556*540*860 | 670*660*950 | 720*950*1020 | 800*1040*1020 | |
| Measuring Targeting System (Standard Accessories) | Camera: 1.3MP Color Camera | ||||
|
Zoom Lens: professional optical lens Magnification of field lens: 0.7–4.5X, WD: 92mm | |||||
| Video Magnification: 28–186X, FOV: 7–1.1mm | |||||
| Scale Resolution: 0.5 μm | |||||
| Z Stroke (mm) | Standard | 200 | |||
| Option | 250–300 | 250–350 | 250–450 | ||
| Accuracy E1* | Ex, y ≤ (3.0+L/200) μm | ||||
| Accuracy E2* | Exy ≤ (4.0+L/200) μm | ||||
| Illumination | Surface light and transmission light adopt LED, brightness adjustable | ||||
| Power | 110/220V(AC), 50/60HZ 30W | ||||
