Gantry CNC Video Measuring System VMG Series

Large Stroke Gantry Cnc Optical Video Measuring Machine VMG Series manufacture

I. Usage

VMG series is latest large stroke gantry type CNC video measuring developed by Yihui.
It adopts original imported from Japan screw drive and servo control technology, combined with our self-developed automated measurement software, it has been widely used in LCD display parts, PCB, communication device parts, sheet metal, space industry and other industries for precision auto measurement.

Designed for rapid precision measurement & batch test in machinery, electronics, mould, etc
1. To measure point, line, circle, arc and oval, rectangular and improve the accuracy with the multi-point positioning function with clear observation.
2. Coordinate measurement, translation and coordinates straighten out.
3. Make measurement data directly into AutoCAD drafting and universal 3D Model file for professional design software like Solidwork, UG & Pro-E.
4. Record user program, editing and execute command.
5. In metrology terms, the machine can test width, length, height, thickness, straightness，flatness, perpendicularity, circular degree, coaxiality, etc.
6. The machine can test products as below:
1) Machinery: sheet, mould & die, gear, turning parts like bearings, shaft.
2) Electronics: phone& tablet sheet, PCB, watch parts, etc.
3) Plastics: mobile phone camera plate, cover, front bezel, slide plate, etc.

II. Features

1. It adopts TEO™ 1 / 2’’ color CCD camera and professional Pomeas™ auto zoom lens, big FOV, guarantee clear image during fast moving image measurement.
2. Grade 00 JINANQING granite base, gantry structure, with German & Japanese auto-control technology, can achieve high precision motion, high stability for measuring large volume work-piece.
3. Programmable control of integrated 40 groups, 8 regional independent light sources, achieve professional surface measurement. Swift batch measurement help to cut labor cost.
4. Coupled with U.S. 2D+3D optical metrology software RationalVue™, wonderfulmeasurement experience.
5. Option Renishaw™ touch probe & Keyence™ laser sensor available, high accuracy composite contact or non-contact 3D measurement available.

Specification

04177…	001	002	003	004	005	006	007
Model	VMG 0203	VMG0405	VMG0608	VMG0810	VMG1012	VMG1215	VMG1518
Glass Size (mm)	300* 400	500* 600	700* 900	900* 1000	1100* 1300	1300* 1600	1600* 1900
X,Y Stroke (mm)	200*300	400* 500	600* 800	800* 1000	1000* 1200	1200* 1500	1500* 1800
Z Stroke(mm)	200
Load Capacity	approx. 35 kg
Dimension (mm)	8201020 1600	1020* 1220*1600	1220* 1520*1600	1420* 1720*1600	1620* 1920*1600	1820* 2220*1600	2120* 2520*1600
Weight(kg)	1000	1250	1380	2000	2500	3000	4000
Resolution	0.5μm
Camera	TEO™ 1 / 2" CCD Camera
Zoom Lens	professional auto zoom lens Zoom lens magnification: 0.7-4.5X
Video Magnification	20-128X
FOV	12.7 mm
Accuracy E1*	Ex,y ≤ (2.8+L/200)μm			Ex,y ≤ (3.5+L/200)μm		Ex,y ≤ (4.5+L/200)μm
Accuracy E2*	Exy ≤ (3.3+L/200)μm			Exy ≤ (4.5+L/200)μm		Exy ≤ (5.8+L/200)μm
Accuracy E3*	Ez ≤ (2.5+L/100) μm
Illumination	Surface and transmitted light source adopt LED, brightness adjustable
