High Accuracy: Ensures precise measurements for complex components.
Video Magnification: Offers 20~128X magnification for detailed analysis.
Low-Cost Solution: Affordable yet highly accurate for precision work.
Product descriptions from the supplier
Highlights at a glance
High Accuracy: Ensures precise measurements for complex components.
Video Magnification: Offers 20~128X magnification for detailed analysis.
Low-Cost Solution: Affordable yet highly accurate for precision work.
Wide Measuring Range: Capable of measuring up to 300x200x200mm.
CE Certified: Meets international safety standards for reliable performance.
III. Specification
| Code | 04172... |
001 VMS-3020E |
002 VMS-4030E |
003 VMS-5040E |
|
| Model | |||||
| Worktable | Worktable D (mm) | 500*330 | 606*466 | 706*566 | |
| Glass Table Size (mm) | 350*280 | 450*350 | 550*450 | ||
| X,Y Stroke (mm) | 300*200 | 400*300 | 500*400 | ||
| Load Capacity | approx. 20 kg | approx. 30 kg | approx. 35 kg | ||
| Resolution | 0.5 μm | 0.5 μm | 0.5 μm | ||
| Accuracy E1* | Ex, y ≤ (3.0+L/200) μm | ||||
| Accuracy E2* | Exy ≤ (3.5+L/200) μm | ||||
| Accuracy E3* | Ez ≤ (3.5+L/150) μm | ||||
| Z Stroke (mm) | Standard | 200 | |||
| Option | 250-300 | 250-350 | 250-450 | ||
| Instrument Weight (kg) | 250 | 325 | 500 | ||
| Dimension (mm) | 610*764*992 | 720*950*1020 | 800*1040*1020 | ||
| Motor | Three-axis Max. Velocity | X,Y: 400mm/s; Z: 200mm/s | |||
| Three-Axis Positioning Accuracy | 0.001mm | ||||
| Imaging System | Camera | 2 MP Color Camera | |||
| Zoom Lens | optical manual zoom lens | ||||
| Zoom Lens Magnification | 0.7-4.5X | ||||
| Video Magnification | 28-186X | ||||
| FOV | 11.1-1.7mm | ||||
| Power Consumption | 600W | ||||
|
Instrument Accessories Zoom Lens Extra Lens 0.5X (option) 1.0X(standard) 2.0X (option) |
1X Tube (standard) | 0.5X Tube (optional) | WD | ||
| 0.7-4.5X | 0.7-4.5X | ||||
| Video Magnification | FOV | Video Magnification | FOV | ||
| 1X-64X | 22-3.4 | 5X-32X | 44-6.8 | 175 | |
| 20X-128X | 11.1-1.7 | 10X-64X | 22-3.4 | 92 | |
| 40X-256X | 5.5-0.9 | 20X-128X | 11.1-1.7 | 36 | |
About this supplier
Dongguan Yihui Optoelectronics Technology Co., Ltd. Established in 2003, has 22-year experience in manufacturing optical instrument and 17-year experience in trading overseas. It is a high-tech enterprise with the precision detection equipment R&D, production and sales. Our main products are: video measurement system, measurement profile projector, CMM, tool microscope, grating sensor, tensile testing machine, environmental testing machine ect. It is including 100 kinds of testing instrument. They are widely used in electronics, plastics, mold, machinery,hardware, clocks, connectors, mobile and other industries. Until 2022, our products have been exporting to 54 countries over the world, and we have formal distributors in KOREA,IRAN, GERMANY and MALAYSIA.Customers from all over the world have been satisfied with our low cost, high efficiency, high quality metrology solutions. Welcome to contact us for cooperation.
